Automatic Plastic Dome Lid Making Machine , HLD - 420 W Plastic Forming Machine

Name: Automatic Plastic Dome Lid Making Machine HLD 420 W Plastic Forming Machine
Brand: Hualida
Price: 1 USD

China Automatic Plastic Dome Lid Making Machine , HLD - 420 W Plastic Forming Machine wholesale

Place of Origin : Zhejiang, China (Mainland)

Brand Name : Hualida

Model Number : HLD-420W

Certification : CE

Price : Negotiable

MOQ : 1 Set/Sets

Processing Type : Plastic Thermoforming Machine

Condition : New

Product Type : Plastic Cup

Voltage : 380V

Dimension(L*W*H) : 2500*1000*1650

Weight : 1000KG, 1200kgs

Warranty : One Year

After-sales Service Provided : Engineers available to service machinery overseas

Cutting frequency : 15 to 45 times/min

Power : 380V/220V/50HZ

Stroke adjustable range : 160mm

Max forming depth : 45mm

Max forming area : 420x160mm

Motor Power : 4kw

Consumption : 0.2m3/min

Pressure : 0.4-0.7mpa

Overall dimensions : 2500x1000x1600mm

Contact Now

HLD-420W Automatic Plastic Dome Lid Thermoforming Machine

Main features:

1. The machine is designed and manufactured by the standard of “GMP” in medical industry and “QS” in food industry.

2. This machine can do forming, punching and blanking at the same time to avoid the cross-contamination of product.

3. The forming heating plate can open and close automatically, also can delay to start, so as to control and lower the waste of the material during the production.

4. Easy to replace the mould, application to different specifications of products.

5. Design the mould according to customer’s requirements.

6. Applicable projects: the material of HIPS, PVC, PET, PS.

Automatic Plastic Dome Lid Making Machine , HLD - 420 W Plastic Forming Machine

Main technical parameters:

Cutting Frequency	15--50times/mins
Power	380v/220v/50HZ
Stroke adjustable range	50--180mm
Max.Forming Depth	30mm
Max.Forming Area	420×180mm
Capacity
Motor Power	1.5kw
Consumption	>0.4m3/min
Pressure	0.4--0.7mpa
Overall Dimensions	2500×1000×1650mm
Weight	1200kg
